Video Input and TransmissionSelf-adaptive HDTVI/HDCVI/AHD/CVBS signal input
Up to 26/34-ch 4 MP IP cameras inputfor DVR-224/232Q-K2
Long distance transmission over UTP and coaxial cable: max. 800m for 1080p and 1200m for 720p HDTVI signal
Compression and RecordingH.265 Pro+/H.265 Pro/H.265/H.264+/H.264 encoding for the main stream, and H.265/H.264 for the sub-stream of analog cameras
Connectable to H.265+/H.265/H.264+/H.264 IP cameras
H.265+ can be enabled to improve encoding efficiency and reduce data storage costs
Full channel recording at up to 4 MP lite resolution
Supports real-time 1080p lite. When 1080p lite is on,the image effect is similar with 1080p
Video OutputSimultaneous HDMI/VGA output
HDMI output at up to 4K (3840 × 2160) resolution
Storage and PlaybackTwo SATA interfaces (up to 10 TB capacity per HDD)
16-ch synchronous playback
Smart search for efficient playback
Suppo
